Product Description:
The Noron Excelon modular air source processor, available in variations such as B72G/B73G/B74G, R72G/R73G/R74G, and F72G series, is a versatile pneumatic processing component that combines filtration, pressure regulation, and oil mist lubrication functions in a single unit. This innovative product is tailored to meet the requirements of industrial compressed air systems.
Key features of the Noron Excelon air source processor include effective elimination of moisture, oil mist, and particulate impurities, as well as the maintenance of stable output pressure and provision of lubrication for pneumatic components. The modular design of the product allows for independent usage or integration with other Excelon components, ensuring flexibility and adaptability in various operational settings.
Applications:
Industrial Manufacturing and Automation
Transportation equipment
Chemical and Energy
Food, pharmaceuticals, and specialty industries
General pneumatic maintenance
| Medium |
Compressed air |
| Operating Temperature |
-34 ... 50 °C, -30 ... 122 °F |
| Port Size |
G3/4 |
| Drain Type |
Manual |
| Maximum Inlet Pressure |
10 bar, 145 psi |
| Lubricator Fog Type |
Micro fog |
| Flow |
73 dm3/sec, 155 scfm |
| Start point |
0.94 dm3/sec, 2 scfm |
| Materials - Body |
Aluminium alloy |
| Materials - Bowl |
Polycarbonate |
| Materials - Elastomers |
Chloroprene rubber, NBR |
| Dimensions - Height |
223 mm |
| Dimensions - Length |
74 mm |
| Dimensions - Width |
80 mm |
| Weight |
0.71 kg |
| Country of Origin |
Mexico, United States |
| Range |
L74M |
| Series |
Excelon |
| Brand |
IMI Norgren |
Support and Services:
The Product Technical Support and Services for the Pneumatic Filter Regulator Lubricator product include:
- Installation guidance and support to ensure proper setup and operation.
- Troubleshooting assistance to address any issues or concerns with the product.
- Maintenance recommendations to enhance the longevity and performance of the equipment.
- Warranty information and claims process for any potential product defects.
- Training resources and materials to help users operate the product effectively.
Packing and Shipping:
Product Name: Pneumatic Filter Regulator Lubricator
Description: This product efficiently filters, regulates, and lubricates pneumatic systems for optimal performance.
Features:
- Filter to remove contaminants
- Regulator to adjust air pressure
- Lubricator to keep components running smoothly
Package Includes:
- 1 Pneumatic Filter Regulator Lubricator
- Mounting hardware
- Instruction manual
Shipping Information:
- Shipping Method: Standard Shipping
- Shipping Time: 3-5 business days
- Shipping Cost: Calculated at checkout
