Product Description:
High precision and excellent stability: Endress+Hauser pressure transmitters provide extremely high measurement accuracy and long-term stability. For example, the accuracy of Cerabar S PMP75 can reach ± 0.075%, and its platinum version can even reach ± 0.05%. Some models, such as the Cerabar PMP71 platinum model, even achieve an accuracy of ± 0.025%
Durable sensor design: The product uses metal (such as 316L, Alloy C276) or ceramic sensors, which can resist overload, corrosion, and wear. Many models can withstand extremely high process pressures (up to 700 bar) and process temperatures (up to 400 ° C), adapting to harsh industrial environments.
Intelligent diagnosis and convenient operation: Multiple transmitters are equipped with Heartbeat Technology, which can perform instrument self calibration as needed without interrupting the production process, and provide complete diagnostic information to help monitor process status or pressure pipe blockage. Devices are usually equipped with touch sensitive displays, menu guided operations, and quick setup menus make debugging and daily operations very convenient.
Modular design and flexible configuration: The product adopts modular design, with replaceable components such as display units and electronic modules, which increases the versatility and maintenance convenience of the equipment.
Sanitary design: For industries with high hygiene requirements such as food, beverage, and pharmaceuticals, some models (such as Cerabar PMP43) adopt a 360 degree no dead corner sanitary design, providing IP69 high protection level to ensure efficient cleaning and avoid product contamination.
Applications:
Process pressure measurement: widely used in various process control fields to continuously measure the absolute and gauge pressures of gases, vapors, or liquids.
Liquid level, volume, and mass measurement: By measuring static pressure, it can be used for measuring the liquid level, volume, or mass of containers or storage tanks. For example, measuring the liquid level in a pressurized tank or distillation tower/evaporator.
Sanitary application: designed specifically for the hygiene industry, suitable for pressure monitoring of process pipelines and static pressure and liquid level measurement of process tanks. The compact design also makes it very suitable for installation in small spaces, such as small volume equipment sleds and devices.
High pressure and high temperature working conditions: With its high pressure and high temperature resistance characteristics, it is suitable for extreme working conditions, such as pressure monitoring of high-pressure reactors or high-temperature steam pipelines in the chemical, petroleum, and natural gas industries.
Safety related systems: Some models (such as Cerabar S PMP75) have safety functions that comply with SIL3 (certified by T ü V S ü D according to IEC 61508 standard) and can be used in safety instrumented systems to achieve a high level of safety integrity.
Support and Services:
The Product Technical Support and Services for the Pneumatic Solenoid Valve include:
- Installation guidance and troubleshooting assistance
- Maintenance recommendations and schedules
- Repair services and spare parts availability
- Product manuals and documentation
- Training programs for users and technicians
Packing and Shipping:
Product Packaging and Shipping:
Our Pneumatic Solenoid Valve is carefully packaged to ensure it reaches you in perfect condition. Each valve is wrapped in protective foam and placed in a sturdy cardboard box. The box is sealed securely to prevent any damage during shipping.
Shipping is handled by our trusted partner, ensuring timely delivery to your specified address. Your order will be shipped within 1-2 business days after payment confirmation. You will receive a tracking number to monitor the status of your delivery.
